Busbar Punching Shearing Bending Machine For Copper 303U-3

What the 303U-3 machine covers

The LT 303U-3 is a CNC single-table busbar processing machine for copper busbar up to 12 mm thick and 160 mm wide, covering the busbar sizes found in most UK distribution boards and consumer assemblies. It punches round, oblong and square holes and performs vertical bending, flat bending and U-bending, so a single machine replaces the punch, shear and bender normally found on three separate benches. LT machines in this class are in service in more than 100 countries, which means die sets and spares are standard supply items rather than one-off manufacture. It suits UK panel shops whose busbar work is dominated by repeat lengths inside the 160 mm window.

Measured performance — 303U-3

Test conditions: Copper busbar processed on a CNC single working table: punching (round, oblong and square holes) and bending (vertical, flat and U-bend).

Measured values: 12 mm maximum processing thickness; 160 mm maximum processing width; 3 hole profiles available (round, oblong, square); 3 bend types available (vertical, flat, U); machine range in service in more than 100 countries.

Benchmark: Where busbar stays inside 12 × 160 mm, this machine covers the whole punch‑bend sequence; the larger LT three-in-one frames are only needed once the bar moves beyond that envelope.
