The LT HQ-600-B is a double head busbar bending machine built for busbar trunking (busway) production, bending the connection bar at both ends in a...
The LT HQ-600-B is a double head busbar bending machine built for busbar trunking (busway) production, bending the connection bar at both ends in a single cycle. Both ends work hydraulically, so pressure is high and repeatable rather than depending on operator force, and the two bends of the bar are formed once instead of in two separate setups. That matters in UK busway manufacture, where a run contains many identical connection bars and each one has to match the last. A large tonnage hydraulic cylinder paired with a high flow gear pump keeps the equipment running at speed, and the major components are known-brand items.
Test conditions: Copper busbar for busbar trunking connection bars, processed on a double head hydraulic machine bending both ends of the bar in one cycle.
Measured values: 2 heads working hydraulically; both bends of the connection bar formed once; large tonnage hydraulic cylinder with high flow gear pump; major components from known brands.
Benchmark: Double head forming against bending each end separately: one cycle produces the finished connection bar, so the second bend cannot drift out of register with the first.
HQ-600-B Double heads busbar trunking system copper bending machine
Main Function:
Double heads bus dust bending press a new type of processing equipment developed by our company,the main functions is bending the two ends of connection busbar of the line of the bus dust,and bending double bends once for each end of the bus dust.No need to change the direction of one bus dust,with the advantages of high processing speed,less steps,high accuracy,saving time and labor etc.
Main Features:
1.This machine mainly for bending the two ends of connection busbar of the line of the bus dust.
2.The two ends of the machine adopts hydraulic working mode, which has the advantages of high pressure, stable performance and so on.
3.The double bends of the two ends of the busbar are formed once, fast processing speed, high efficiency.
4.Large tonnage hydraulic cylinder with large flow gear pump, to ensure the running speed of the equipment.
5.Major components are well-known brands, to ensure the stability of the device.
Nominal pressure
600KN
Machining range
3 * 30-6 * 200mm
Overall size
3600 * 1500 * 1000mm
high efficiency
